| Model | VB0707 | |
|---|---|---|
| Cutting height | 700 mm (27.6″) | |
| Cutting depth | 700 mm (27.6″) | |
| Cutting length | 1.5/2.5 M | |
| Table support width | Outer table | 700 mm (27.6″) |
| Inner table | 700 mm (27.6″) | |
| Blade size | 6800 x 54 x 1.6 mm (267.7″ x 2″ x 0.06″) | |
| Blade speed | 15-75 m/min (50 to 250 fpm) | |
| Cutting feed | Hydraulic | |
| Motor | Blade drive | 5.5 kW (7.5 HP) |
| Hydraulic pump | 1.5 kW (2 HP) | |
| Coolant pump | 0.7 kW (1 HP) | |
| Table height | 1600 mm (63″) | |
| Machine height | 3700 mm (145.7”) | |
| Floor space | 6400L x 2550W mm (252” x 100.4”) (1.5M) n7000L x 2550W mm (275.6” x 100.4”) (2.5M) |
|
| Machine weight (approx.) | 9000 kgs (19842 lbs) (1.5M) n11500 kgs (25353 lbs) (2.5M) |
|
